The image on the right is both beautiful and exciting. Let me explain why. It’s the paw of an embryonic mouse and a team of geneticists have inserted a fragment of human DNA into its cells. The fragment contains an “enhancer” element, a short span of DNA that switches other genes on and off; in this case, they put the enhancer in control of a gene whose activity creates a blue chemical.
This particular enhancer is called HACNS1. Throughout the course of animal evolution, its sequence has gone relatively unchanged in almost all back-boned animals, but it has evolved rapidly in the human genome since we split away from chimpanzees. So the blue patch in this image shows where this rapidly-evolved, human-specific piece of DNA is triggering genetic activity in the paw of a mouse. Figured out why it’s exciting yet? It’s in the bit that will eventually become a thumb.
HACNS1 controls genes but it isn’t one itself. It is part of the large majority of our genome known as “non-coding DNA“. A small proportion of our DNA is a code that tells our cells how to build its workforce of proteins, but the majority is never translated in this way. Much of this “non-coding DNA” is functionless junk, but some types are very important indeed.
The enhancers are one such group. They are stretches of DNA that control the activity of genes, which can often lie some distance away from the enhancer. When “activator” proteins stick to the enhancers, the target gene is switched on.
Change the sequence of these enhancers and you can change which genes they control, when they do so and where they do so. It’s one way for evolution to exact big changes in a creature’s body without having to add much in the way of genetic innovation. By changing enhancers, it can simply redeploy the existing squad of genes in new and interesting ways. The results can be dramatic, much like changing a sports manager can have a greater impact on a team’s performance than switching out individual players.
There’s evidence that these sorts of changes have indeed happened. Many human non-coding sequences show signs of incredibly rapid evolution ever since our evolutionary path diverged from that of chimps some six million years ago. Shyam Prabhakar from the Lawrence Berkeley National Laboratory singled out HACNS1 for attention because it is the most rapidly evolving sequence of its kind.
Only 16 differences separate HACNS1’s sequence from that of its chimp counterpart, but that’s about 4 times as many as you would have expected if the sequence had just been drifting aimlessly while picking up new mutations. These rapid changes are a clear sign of “positive selection”, where new mutations bestow such advantages on their bearers that they spread rapidly throughout the population.
So what does HACNS1 do? To find out, Prabhakar (together with a large team of geneticists) placed the human, chimp and macaque versions in a strain of mice. They set things up so that the sequence had control over a gene that creates a blue chemical when it’s active. At the time, no one knew if HACNS1 was an enhancer; that only became apparent when they saw patches of blue in the young mouse embryos.
Embryos that were loaded with the human version had strong blue stains in their developing limbs, eyes, ears and pharyngeal arches (structures that will eventually become the muscles, bones and organs of the mouth and throat). As the embryo develops, HACNS1 is clearly acting as a gene enhancer in these body parts. In comparison, the chimp and macaque versions drove very little gene activity at these sites, particularly at the limbs, where many embryos had no signs of blue colour at all.
When the team looked at older embryos, they saw that the enhancer was still activating genes in the young mouse’s limbs. They saw the telltale blue stain in the shoulder, wrist and thumb of the front limbs and to a lesser extent in the big toe, ankle and hip of the hind pair. Once again, the chimp and macaque enhancers were far less enhancing, and only drove a smattering of gene activity in the shoulder area.
The results are preliminary but they are exciting. They suggest that changes in HACNS1 may have contributed to the uniquely human aspects of our thumbs, wrists, ankles and feet. Our long and fully opposable thumbs allow us to grip and manipulate objects with great precision while our inflexible feet and short toes give us the stability that life on two feet demands. There’s no doubt that these physical innovations have played a key part in our success as a species, and perhaps HACNS1 can take some credit for that.
Prabhakar’s team found further proof of the uniqueness of human HACNS1 with a deceptively simple game of genetic swapsies. They added all 16 human-specific changes to the chimpanzee version, and also stripped out all 16 changes from the human sequence to revert it back to the chimp one. In the mouse embryos, the “humanised” chimp enhancer produced the same pattern of blue as the natural human version did (compare top right embyros with bottom left), while the “reverted” human enhancer yielded the same pattern as the untouched chimp and macaque ones (compare bottom right with top left).
These 16 genetic tweaks have raised HACNS1’s profile, turning it from a bit-part actor into one of the major stars in the drama of development. It’s not entirely clear how this has happened, but a quick analysis showed that the 16 changes have probably altered the way that the enhancer interacts with its activator proteins. The proteins attach to the enhancer through specific docking sites that are dictated by its sequence. As this sequence changed in 16 ways, docking sites were added for some proteins and lost for others.
The next part of the quest will be to find which genes are enhanced by the enhancer. The closest two are CENTG2, whose role in limb development has never been looked at, and GBX2, which is activated in embryonic limbs. Nor is the role of HACNS1 confined to limbs – it’s also activated in eyes, ears and the precursors of mouths. And perhaps there are other organs that are affected in humans but don’t show up in the mouse embryos. These are all questions for another time. For now, the results can be taken as yet further evidence that many of evolution’s big breakthroughs, from eyes to language, are the result of genetic tinkering rather than novelty.
Images: from Science
